CREE Xlamp XMLCTW Rgb Led Chip CREE Xlamp XML Color RGBW XMLCTW

Product Categories

One Plus Lighting Co., Ltd.

Contact Now

MOQ : 1000

Size : 5 x 5 mm

Product Options : Color (RGBW in one package)

Maximum Drive Current (Standard) : 1 A per LED die

Maximum Efficacy at Binning Conditions (lm/W) : 111 lm/W

Typical Forward Voltage : 2.25 V per LED die Red @ 350 mA 3.3 V per LED die Green @ 350 mA 3.1 V per LED die Royal Blue and White @ 350 mA

Viewing Angle : 130 °

Reflow Solderable : Yes - JEDEC J-STD-020C-compatible

Contact Now

CREE Xlamp XML Color RGBW XMLCTW With Red Green ,Royal-Blue and White in one LED Applicated in Stage light

Size	5 x 5 mm
Product Options	Color (RGBW in one package)
Maximum Drive Current (Standard)	1 A per LED die
Maximum Efficacy at Binning Conditions (lm/W)	111 lm/W
Typical Forward Voltage	2.25 V per LED die Red @ 350 mA
	3.3 V per LED die Green @ 350 mA
	3.1 V per LED die Royal Blue and White @ 350 mA
Viewing Angle	130 °
Maximum Junction Temperature	150 °C
Maximum ESD Withstand Voltage	8000 V (HBM per Mil-Std-883D)
Reflow Solderable	Yes - JEDEC J-STD-020C-compatible
RoHS-Compliant	Yes
REACh-Compliant	Yes

CREE Xlamp XMLCTW Rgb Led Chip CREE Xlamp XML Color RGBW XMLCTW
